General Specifications

Platform:

Desktop

Market Segment:

Mainstream Desktop

Product Family:

AMD Ryzen™ Processors

Product Line:

AMD Ryzen™ 5 Desktop Processors

Consumer Use:

Yes

Regional Availability:

Global, China, NA, EMEA, APJ, LATAM

Former Codename:

“Renoir”

Architecture:

“Zen 2”

# of CPU Cores:

6

Multithreading (SMT):

Yes

# of Threads:

12

Max. Boost Clock:

Up to 4.1GHz

Base Clock:

3.6GHz

L1 Cache:

384KB

L2 Cache:

3MB

L3 Cache:

8MB

Default TDP:

65W

Processor Technology for CPU Cores:

TSMC 7nm FinFET

CPU Compute Die (CCD) Size:

180mm²

Package Die Count:

1

Unlocked for Overclocking:

Yes

CPU Socket:

AM4

Socket Count:

1P

Supporting Chipsets:

X570
X470
X370
B550
B450
B350
A520
A320

CPU Boost Technology:

Precision Boost 2

Instruction Set:

x86-64

Supported Extensions:

AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Thermal Solution (PIB):

AMD Wraith Stealth

Max. Operating Temperature (Tjmax):

95°C

Launch Date:

4/4/2022

*OS Support:

Windows 11 – 64-Bit Edition
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.

Connectivity

USB Type-C® Support:

Yes

Native USB 3.2 Gen 2 (10Gbps) Ports:

4

Native USB 3.2 Gen 1 (5Gbps) Ports:

0

Native USB 2.0 (480Mbps) Ports:

0

Native SATA Ports:

2

PCI Express® Version:

PCIe® 3.0

Native PCIe® Lanes (Total/Usable):

24/20

Additional Usable PCIe Lanes from Motherboard:

AMD X570
AMD X470
AMD X470

16x Gen 3
2x Gen 3
8x Gen 2

NVMe Support:

Boot, RAID0, RAID1, RAID10

System Memory Type:

DDR4

Memory Channels:

2

Max. Memory:

128GB

System Memory Subtype:

UDIMM

System Memory Specification:

Up to 3200MHz

Max Memory Speed:

ECC Support:

No

Graphics Capabilities

Integrated Graphics:

No

Graphics Model:

Discrete Graphics Card Required

Product IDs

Product ID Boxed:

100-100000644BOX

Product ID Tray:

100-000000644

Key Features

Supported Technologies:

AMD StoreMI Technology
AMD “Zen 2” Core Architecture
AMD Ryzen™ VR-Ready Premium
