ASUS ROG Strix B365-F Gaming Mainboard

Giá: 3.590.000VND
  • Hỗ trợ chip Intel thế hệ 8 và 9 mới nhất hiện nay
  • Đèn LED RGB Aura Sync đồng bộ hệ thống ánh sáng máy tính bạn
  • Dễ dàng tự lắp ráp, I/O shield lắp sẵn, ASUS SafeSlot bảo vệ linh kiện
  • Kết nối gaming, Dual M.2, USB 3.1 thế hệ 2 Type-A, DisplayPort
  • Lá tản nhiệt M.2 có sẵn, giúp ổ cứng M.2 hoạt động ổn định
  • Mạng gaming, Intel Gigabit Ethernet, LANGuard, GameFirst
  • Âm thanh gaming: SupremeFX S1220A với SonicStudio III cao cấp
CPU hỗ trợ Intel® Socket 1151 9th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors
Supports Intel® 14 nm CPU
* The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
Chipset Intel® B365
Bộ nhớ trong 4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
Hiển thị đồ họa Integrated Graphics Processor- Intel® HD Graphics support
Multi-VGA output support : HDMI/DVI/DisplayPort ports
– Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
– Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
– Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz *1
Hỗ trợ Multi-GPU Supports AMD 2-Way CrossFireX Technology
Khe mở rộng 1 x PCIe 3.0/2.0 x16 (x16 mode)
1 x PCIe 3.0/2.0 x16 (x4 mode) *2
3 x PCIe 3.0/2.0 x1 *3
Chuẩn lưu trữ Intel® B365 Chipset :
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*4
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
6 x SATA 6Gb/s port(s)
Intel® Rapid Storage Technology supports
Intel® Optane™ Memory Ready
Mạng Intel® I219V, 1 x Gigabit LAN Controller(s)
Anti-surge LANGuard
ROG GameFirst Technology
Âm Thanh ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
– Dual Headphone Amplifiers
– Impedance sense for front and rear headphone outputs
– Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
– High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
– SupremeFX Shielding Technology
– Supports up to 32-Bit/192kHz playback *6
Audio Feature :
– Optical S/PDIF out port(s) at back panel
– Sonic Radar III
– Sonic Studio III + Sonic Studio Link
Kết nối ngoài 1 x PS/2 keyboard/mouse combo port(s)
1 x DVI-D
1 x DisplayPort
1 x HDMI
1 x LAN (RJ45) port(s)
2 x USB 3.1 Gen 2 (red)Type-A,
2 x USB 3.1 Gen 1 (black) Type-A + USB Type-CTM
4 x USB 2.0
1 x Optical S/PDIF out
5 x Audio jack(s)
Kết nối trong 1 x AAFP connector
1 x Aura RGB Strip Header(s)
1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
1 x M.2 with E key for Wi-Fi module
6 x SATA 6Gb/s connector(s)
1 x M.2_FAN connector
1 x CPU Fan connector(s)
1 x CPU OPT Fan connector(s)
2 x Chassis Fan connector(s)
1 x AIO_PUMP connector
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x System panel(s)
1 x 5-pin EXT_FAN(Extension Fan) connector
1 x Thermal sensor connector(s)
1 x Clear CMOS jumper(s)
1 x 14-1 pin TPM connector
1 x COM port header
Kích thước ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )



  • Sản phẩm được bảo hành chính hãng 3 năm
