THREE TYPES ARGB EXTENSION CABLES
Evolution of the award-winning STRIMER and STRIMER PLUS that puts the finishing RGB touch on your PC.

STRIMER PLUS V2 24-PIN
for motherboard connector

STRIMER PLUS V2 3×8-PIN
for triple 8 PIN GPU connector

STRIMER PLUS V2 8-PIN
for dual 8 PIN GPU connector

12+4-PIN to 12+4-PIN
12 light guides
For 12VHPWR GPU connector

12+4-PIN to 12+4-PIN
8 light guides
For 12VHPWR GPU connector

3X8 PIN to 12+4-PIN
8 light guides
For 12VHPWR GPU connector
SUPPORTS UP TO:
450 W, if power supply PCIe cable is 18 Awg.
600 W, if power supply PCIe cable is 16 Awg.
LAST PIECE OF RGB SET-UP YOU NEED
Upgrade the RGB in your PC with the ARGB extension cables.

Next Level of Brightness
Introduce a new side light strip, brightening STRIMER PLUS V2 in different ways.

STRIMER PLUS V2

STRIMER PLUS V1
Numerous LEDs
Allocating many LEDs evenly to glow your build with complex lighting effects.

24-PIN
12 light guides
120 LEDs

8-PIN
12 light guides
162 LEDs

3×8-PIN
8 light guides
108 LEDs

12+4-PIN to 12+4-PIN
12 light guides
162 LEDs

12+4-PIN to 12+4-PIN
8 light guides
108 LEDs

3×8-PIN to 12+4-PIN
8 light guides
108 LEDs
Smooth Lighting Style
Illuminate the STRIMER PLUS V2 with a sleek design by reducing the lighting strips width to 2.1mm.

STRIMER PLUS V2

STRIMER PLUS V1
STRAIGHTFORWARD INSTALLATION
Install STRIMER PLUS V2 12VHPWR with perfect curvature and sparkle your build with RGB.


Slim and Flexible
The thickness of the RGB zone and the cable on the V2 are reduced to 8mm, ensuring flexibility for all kinds of configuration.


STRIMER PLUS V2
STRIMER PLUS V2
Flexible Clearance
A minimum of 28mm of clearance is required when installing the 12VHPWR connector. For situations where less clearance is available, the plastic shield can be removed to reduce the required clearance to 23mm.


Match the Color of your Build
Includes extra white clips to match the hardware color inside your PC.


ARGB SYNCHRONIZATION WITH THE MOTHERBOARD
The GPU extension cable has a 3 PIN 5V ARGB adaptor to connect to the motherboard directly.
Note: Lower 50% of the brightness when applying static white.
(Check detailed instructions from manual)


ADDITIONAL ACCESSORY
STRIMER L-CONNECT 3 CONTROLLER
The controller that is included in STRIMER PLUS V2 24-PIN (or available separately) offers full control of L-Connect 3.


❶
Connect to PSU SATA Cable
Note: If using the static white lighting effect frequently, please connect to the SATA header as close to the PSU as possible an do not connect other ARGB dervice (eg. UNI HUB) to the same sata cable.
❷
Connect to
MB 5V ARGB header
❸
Connect to
MB USB 2.0 header
PHẦN MỀM L-CONNECT 3 ĐIỀU KHIỂN STRIMER PLUS V2
Kiểm soát và xem trước chính xác hiệu ứng ánh sáng của STRIMER PLUS V2 với giao diện L-Connect mới.

UNLOCK YOUR IMAGINATION OF LIGHTING EFFECTS
Without the need of opening the case, STRIMER PLUS can now be controlled via the L-Connect 3 software with 11 Individual modes and 13 combined lighting modes. The highly customizable software brings the option of setting different sophisticated lighting effects on each STRIMER PLUS or even on each channel (2 light strips).
Combined Lighting Effects
Display your PC with the new combining lighting effects.
Individual Channel Lighting Effects
With 24-pin at 6 channels, the Dual 8-pin at 4 channels, and the triple 8-pin at 6 channels, plenty of personalized light effects can be accomplished by L-Connect 3.

Quick Sync with UNI FANs
The quick sync function efficiently syncs all LIAN LI devices’ lighting effects in one click. Moreover, you can sync all devices to the motherboard.

PACKAGE CONTENT

24-PIN
12 light guides
Include Controller for L-Connect 3

8-PIN
12 light guides
Include MB ARGB 3-PIN cable adaptor

3×8-PIN
8 light guides
Include MB ARGB 3-PIN cable adaptor

12+4-PIN to 12+4-PIN
12 light guides
Include MB ARGB 3-PIN cable adaptor

12+4-PIN to 12+4-PIN
8 light guides
Include MB ARGB 3-PIN cable adaptor

3X8 PIN to 12+4-PIN
8 light guides
Include MB ARGB 3-PIN cable adaptor
PRODUCT NAME
LIAN LI ADDRESSABLE RGB STRIMER PLUS V2 24-PIN
LIAN LI ADDRESSABLE RGB STRIMER PLUS V2 8-PIN
LIAN LI ADDRESSABLE RGB STRIMER PLUS V2 TRIPLE 8-PIN
MODEL
PW24-PV2
PW8-PV2
PW12-PV2
DIMENSIONS
267mm(L )X 56.6mm (D) X 8mm(H)
345mm(L) X 43.5mm (D) X 8mm(H)
345mm(L) X 56.3mm (D) X 8mm(H)
MATERIAL
SILICONE/TPE
CABLE LENGH
220mm
300mm
300mm
GAUGE
18AWG
NUMBER OF LEDS
120
108
162
ACCESSORIES
Controller for L-Connect 3
Cable Adaptor for Motherboard ARGB 3-Pin
Cable Adaptor for Motherboard ARGB 3-Pin
PRODUCT NAME
STRIMER PLUS V2 12VHPWR
MODEL
PW16-12PV2
PW16-8PV2
PW168-8PV2
FEMALE CONNECTOR
12+4pin
12+4pin
3x8pin
MALE CONNECTOR
12+4pin
12+4pin
12+4pin
DIMENSIONS
381mm (L) X 56.4mm (D) X 8mm (H)
381mm (L) X 39.8mm (D) X 8mm (H)
381mm (L) X 39.8mm (D) X 8mm (H)
MATERIAL
SILICONE/TPE
CABLE LENGH
320mm
320mm
335mm
GAUGE
16AWG
LIGHT GUIDES
12
8
8
NUMBER OF LEDS
162
108
108
ACCESSORIES
Cable adaptor for motherboard ARGB 3-PIN
- Bảo hành 12 tháng
PRODUCT NAME | LIAN LI ADDRESSABLE RGB STRIMER PLUS V2 24-PIN | LIAN LI ADDRESSABLE RGB STRIMER PLUS V2 8-PIN | LIAN LI ADDRESSABLE RGB STRIMER PLUS V2 TRIPLE 8-PIN |
---|---|---|---|
MODEL | PW24-PV2 | PW8-PV2 | PW12-PV2 |
DIMENSIONS | 267mm(L )X 56.6mm (D) X 8mm(H) | 345mm(L) X 43.5mm (D) X 8mm(H) | 345mm(L) X 56.3mm (D) X 8mm(H) |
MATERIAL | SILICONE/TPE | ||
CABLE LENGH | 220mm | 300mm | 300mm |
GAUGE | 18AWG | ||
NUMBER OF LEDS | 120 | 108 | 162 |
ACCESSORIES | Controller for L-Connect 3 | Cable Adaptor for Motherboard ARGB 3-Pin | Cable Adaptor for Motherboard ARGB 3-Pin |
WARRANTY | 1 year |
PRODUCT NAME | STRIMER PLUS V2 12VHPWR | ||
---|---|---|---|
MODEL | PW16-12PV2 | PW16-8PV2 | PW168-8PV2 |
FEMALE CONNECTOR | 12+4pin | 12+4pin | 3x8pin |
MALE CONNECTOR | 12+4pin | 12+4pin | 12+4pin |
DIMENSIONS | 381mm (L) X 56.4mm (D) X 8mm (H) | 381mm (L) X 39.8mm (D) X 8mm (H) | 381mm (L) X 39.8mm (D) X 8mm (H) |
MATERIAL | SILICONE/TPE | ||
CABLE LENGTH | 320mm | 320mm | 335mm |
GAUGE | 16AWG | ||
LIGHT GUIDES | 12 | 8 | 8 |
NUMBER OF LEDS | 162 | 108 | 108 |
ACCESSORIES | Cable adaptor for motherboard ARGB 3-PIN | ||
WARRANTY | 1 year |
