SPECIFICATIONS
Model
SP750
DIMENSIONS
(DxWxH)
100 mm x 63.5mm x 125 mm
POWER SUPPLY DESIGN
Fully modular
COLOR
Black / White
MATERIAL
Steel/brushed aluminum housing
FORM FACTOR
SFX
CERTIFICATION
80 PLUS Gold
MAX. DC OUTPUT
750w
COMBINED +3.3V & +5V
100W
COMBINED +12V
744W
INPUT VOLTAGE
100 – 240 Vrms
INPUT FREQUENCY RANGE
50Hz – 60 Hz
PFC
Active PFC (PF)>0.90 at full load
EFFICIENCY
91.89% Max
PROTECTIVE CIRCUIT
OCP/ OPP/ UVP/ OVP/ OTP/ SCP
CONNECTORS
- 1 x 24 / 20-Pin motherboard connector (300mm) x 1pcs
- 2 x 8 / 4-Pin CPU / ATX 12V connector (450mm-70mm) x 1 pcs
- 1 x 8 / 6+2 Pin PCIe connector (400mm) x 1pcs
- 2 x 8 / 6+2 Pin PCIe connector (400mm-120mm) x 1pcs
- 4 x SATA connector (120mm-120mm-120mm-120mm) x 2pcs
- 4 x 4-Pin Peripheral connector (120mm-120mm-120mm-120mm) x 1pcs
750W FAN RPM
1000-2800 RPM
NOISE LEVEL
17.1-43.1 DBA
BEARING TYPE
31.Fluid Dynamic Bearing (FDB)
WARRANTY
5 years
