General
Vendor
Intel
Released
October 17, 2023
Type
Desktop
instruction set
x86-64
Codename
Raptor Lake Refresh
Model number
i9-14900F
Integrated GPU
No
CPU
ο Performance Cores
P-Cores
8
P-Threads
16
Base Frequency (P)
2.0 GHz
Turbo Boost Frequency (P)
5.8 GHz
ο Efficient Cores
E-Cores
16
E-Threads
16
Base Frequency (P)
1.5 GHz
Turbo Boost Frequency (P)
4.4 GHz
ο Total
Total Cores
24
Total Threads
32
Bus Frequency
100 MHz
Multiplier
20x
L1 Cache
80K (per core)
L2 Cache
2MB (per core)
L3 Cache
36MB (shared)
Unlocked Multiplier
No
Package
Fabrication process
10 nm
TDP (PL1)
65 W
Max. Boost TDP (PL2)
219 W
Socket
LGA-1700
Peak temperature
100°C
Memory Support
Memory types
– DDR5-6000
– DDR4-3200
Memory Size
128 GB
Max. Memory Channels
2
Max. Memory Bandwidth
ECC Support
Yes
Misc
PCI Express Version
5.0
PCI Express Lanes
20
- Bảo hành 36 tháng theo hộp
