CÔNG NGHỆ MỚI NHẤT ĐỂ TRẢI NGHIỆM GAME

1. Kiến trúc “Zen 5” 1 cho phép hiệu quả năng lượng lãnh đạo hơn thế hệ trước
2. Nền tảng AMD Socket AM5 sẵn sàng cho tương lai
3. AMD Ryzen™ Master dễ dàng cá nhân hóa hiệu suất của bạn
4. Công nghệ AMD EXPO™ có thể mở khóa hiệu suất bộ nhớ được cải thiện để chơi game nhanh hơn 4
5. PCIe Gen 5 với khả năng băng thông cao hơn
6. Khả năng AI AMD Radeon™ sẵn sàng khi ghép nối bộ xử lý Ryzen™ 9000 series với đồ họa Radeon™ 7000 Series, lý tưởng cho các ứng dụng AI dành cho người dùng đam mê

1. The information contained herein is for informational purposes only, and is subject to change without notice. Timelines, roadmaps, and/or product release dates shown herein are plans only and subject to change. “Zen 5” is a codename for AMD architectures, and are not product names. GD-122
2. Max boost for AMD Ryzen processors is the maximum frequency achievable by a single core on the processor running a bursty single-threaded workload. Max boost will vary based on several factors, including, but not limited to: thermal paste; system cooling; motherboard design and BIOS; the latest AMD chipset driver; and the latest OS updates. GD-150.
3. Precision Boost Overdrive requires an AMD Ryzen Threadripper or a Ryzen 3000/4000/5000 series desktop processor, and a compatible motherboard. AMD Ryzen 3400G and 3200G series processors are not compatible. Because Precision Boost Overdrive enables operation of the processor outside of AMD’s published specifications, use of the feature invalidates the AMD product warranty and may also void warranties offered by the system manufacturer or retailer. Availability of Precision Boost Overdrive in pre-built OEM desktop systems will vary based on the PC manufacturer’s settings. Check with the PC manufacturer prior to purchase. GD-179.
4. Testing as of Dec 2023 by AMD Performance Labs on a test system configured with a Ryzen 7 5700X3D, Nvidia GeForce GTX 4080 graphics, Gigabyte X570S Aorus Master motherboard, 32GB 6400MHz RAM (2x16GB), Samsung 980 Pro 1TB NVMe, and Windows 11 Pro vs. A similarly configured system with an Intel Core i5-13600KF, Nvidia GeForce GTX 4080 graphics, ROG Strix Z790-E Gaming Wifi motherboard, 32GB 6400MHz RAM (2x16GB), Samsung 980 Pro 1TB NVMe, and Windows 11 Pro on the following titles at 1080p, VBS enabled, high details: Control, Naraka: Bladepoint, World of Tanks, Watch Dogs: Legion, Call of Duty: Modern Warfare, Red Dead Redemption 2, Rainbow Six Seige, Shadow of the Tomb Raider, Mount & Blade 2, DOTA2, PUBG, Dying Light 2. System manufacturers may vary configurations, yielding different results. R5K-128.
© 2024 Advanced Micro Devices, Inc. All rights reserved. AMD, the AMD Arrow logo, Ryzen, Radeon, and combinations thereof are trademarks of Advanced Micro Devices, Inc. Other product names used in this publication are for identification purposes only and may be trademarks of their respective owners. PID# 242745666-D
General Specifications
- Name:
AMD Ryzen™ 9 9950X3D
- Family:
Ryzen
- Series:
Ryzen 9000 Series
- Form Factor:
Desktops , Boxed Processor
- Market Segment:
Enthusiast Desktop
- AMD PRO Technologies:
No
- Regional Availability:
Global
- Former Codename:
Granite Ridge AM5
- Architecture:
Zen 5
- # of CPU Cores:
16
- Multithreading (SMT):
Yes
- # of Threads:
32
- Max. Boost Clock:
Up to 5.7 GHz
- Base Clock:
4.3 GHz
- L1 Cache:
1280 KB
- L2 Cache:
16 MB
- L3 Cache:
64 MB
- Default TDP:
170W
- Processor Technology for CPU Cores:
TSMC 4nm FinFET
- Processor Technology for I/O Die:
TSMC 6nm FinFET
- Package Die Count:
3
- Unlocked for Overclocking:
Yes
- AMD EXPO™ Memory Overclocking Technology:
Yes
- Precision Boost Overdrive:
Yes
- Curve Optimizer Voltage Offsets:
Yes
- AMD Ryzen™ Master Support:
Yes
- CPU Socket:
AM5
- Supporting Chipsets:
A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850
- CPU Boost Technology:
Precision Boost 2
- Instruction Set:
x86-64
- Supported Extensions:
AES , AVX512 , AVX2 , AVX , FMA3 , MMX-plus , SSE2 , SSE4.2 , SSE4A , SSE4.1 , SSE3 , SSSE3 , SSE , x86-64
- Thermal Solution (PIB):
Not Included
- Recommended Cooler:
Liquid cooler recommended for optimal performance
- Max. Operating Temperature (Tjmax):
95°C
- *OS Support:
Windows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
Connectivity
- Native USB 3.2 Gen 2 (10Gbps) Ports:
4
- Native USB 2.0 (480Mbps) Ports:
1
- PCI Express® Version:
PCIe® 5.0
- Native PCIe® Lanes (Total/Usable):
28 , 24
- NVMe Support:
Boot , RAID0 , RAID1 , RAID5 , RAID10
- System Memory Type:
DDR5
- Memory Channels:
2
- Max. Memory:
192 GB
- System Memory Subtype:
UDIMM
- Max Memory Speed:
2x1R
2x2R
4X1R
4x2R
DDR5-5600
DDR5-5600
DDR5-3600
DDR5-3600
- ECC Support:
Yes (Requires mobo support)
Graphics Capabilities
- Graphics Model:
AMD Radeon™ Graphics
- Graphics Core Count:
2
- Graphics Frequency:
2200 MHz
- USB Type-C® DisplayPort™ Alternate Mode:
Yes
Product IDs
- Product ID Boxed:
100-100000719WOF
- Product ID Tray:
100-000000719
Key Feature
- Supported Technologies:
AMD EXPO™ Technology , AMD Ryzen™ Technologies
