1. The information contained herein is for informational purposes only, and is subject to change without notice. Timelines, roadmaps, and/or product release dates shown herein are plans only and subject to change. “Zen 2” is a codename for AMD architectures, and are not product names. GD-122
2. Max boost for AMD Ryzen processors is the maximum frequency achievable by a single core on the processor running a bursty single-threaded workload. Max boost will vary based on several factors, including, but not limited to: thermal paste; system cooling; motherboard design and BIOS; the latest AMD chipset driver; and the latest OS updates. GD-150.
3. Precision Boost Overdrive requires an AMD Ryzen Threadripper or a Ryzen 3000/4000/5000 series desktop processor, and a compatible motherboard. AMD Ryzen 3400G and 3200G series processors are not compatible. Because Precision Boost Overdrive enables operation of the processor outside of AMD’s published specifications, use of the feature invalidates the AMD product warranty and may also void warranties offered by the system manufacturer or retailer. Availability of Precision Boost Overdrive in pre-built OEM desktop systems will vary based on the PC manufacturer’s settings. Check with the PC manufacturer prior to purchase. GD-179.
©2022 Advanced Micro Devices, Inc. All rights reserved. AMD, the AMD Arrow logo, Ryzen, Radeon, and combinations thereof are trademarks of Advanced Micro Devices, Inc. Other product names used in this publication are for identification purposes only and may be trademarks of their respective owners.
Thông Số Kỹ Thuật
- Dòng Sản Phẩm:
Bộ Xử Lý AMD Ryzen™
- Loại Sản Phẩm:
Bộ Xử Lý AMD Ryzen™ 3
- Số Nhân:
4
- Số Luồng:
8
- Xung Nhịp Tối Đa:
Lên tới 4.0GHz
- Xung Nhịp Cơ Bản:
3.8GHz
- Bộ Nhớ Đệm L1:
256KB
- Bộ Nhớ Đệm L2:
2MB
- Bộ Nhớ Đệm L3:
4MB
- TDP Mặc Định:
65W
- Tiến Trình Sản Xuất:
TSMC 7nm FinFET
- Mở Khóa Ép Xung:
Có
- CPU Socket:
AM4
- Số Lượng Socket:
1P
- Tản Nhiệt Đi Kèm (PIB):
Tản Nhiệt AMD Wraith Stealth
- Nhiệt Độ Hoạt Động Tối Đa:
(Tjmax)95°C
- Thời Gian Ra Mắt:
04/04/2022
- *Hỗ Trợ Hệ Điều Hành:
Windows 11 – 64-Bit Edition
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Hỗ trợ Hệ điều hành (OS) sẽ khác nhau tùy theo nhà sản xuất.
Connectivity
- Phiên Bản PCI Express®:
PCIe 3.0
- Loại RAM Hỗ Trợ:
DDR4
- Hỗ Trợ Bộ Nhớ Kênh:
2
- Xung Nhịp RAM:
Lên tới 3200MT/s
- Tốc Độ Bộ Nhớ Tối Đa:
2x1R
2x2R
4x1R
4x2R
DDR4-3200
DDR4-3200
DDR4-2933
DDR4-2667
Product IDs
- Product ID Boxed:
100-100000510BOX
- Product ID Tray:
100-000000510
Key Features
- Công Nghệ Được Hỗ Trợ:
AMD StoreMI Technology
AMD “Zen 2” Core Architecture
AMD Ryzen™ VR-Ready Premium
